Product Description
ANSI B16.47 32" Slip-On Flange
Standard: ANSI; ASMT; ASME; JIS; DIN; SIS; GB
Material: Carbon steel; Alloy steel; Stainless steel.
Customer's design is welcomed.
DHDZ is a major manufacturer of various forgings.
Such as forged SHAFT, forged RING; Forged BLOCK; Forged FLANGE.
Pipe sheet, gear ring, slewing bearing ring... Most of forging parts.
SINHOO has more than 150 customers in the world, the famous ones are:
*ABB-Shaft; Cylinder
*Siemens, -large size forgings 5M length shaft
*SINOPEC-flanges.
Lap joint flange
Model: LJF1
Material: Carbon steel A36/A105/Rst37.2/C22.8/Q235 Stainless steel 304/304L, 316/316L, 321, A350 LF2, F60 ect.
Size: 1/2"-24"
Pressure: 150lbs-2500lbs
Facing: RF/FF/RTJ
Standard: ANSI B16.5
Wall thickness: SCH40, STD, ect and other wall thickness you required.
Flanges (ASTM, JIS, DIN, ANSI)
Standards: ANSI, BS, DIN, JIS and MSS etc.
Materials: Carbon steel, Stainless steel and Alloy steel etc.
Size: 1/2" ~ 64"(DN15 mm ~ 1600 mm)
Type: Slip-On, Welding Neck, Blind, Socket Welding, Threaded, Lap Joint and Plate etc.
Pressure Ratings: Class 150, 300, 600, 900, 1500 and 2500
Pressure Ratings: PN 6, PN 10, PN16, PN25, PN40 and PN64
Pressure Ratings: JIS 5K, 10K, 16K and 20K
Thread flange
1: 1/2"--86", 150lb--2500lb
2, types: BL PL SO WN THR OWN SW
3, Standard: ASME/ANSI DIN JIS GB BS EN
4, Material: A105, Q235, A350 LF2, F304, F316, F5/9/11
5, Delivery time: 7--20days after the order confirmed
7, Payment Terms: (1)T/T: 30%T/T advance, 70%balance copy of B/L; (2) L/C: At sight (3) T/T and L/C: 40%T/T advance, 60%L/C at sight (4)Western Union
Forged Steel Flanges:
* ASME/ANSI B16.5: WELDING NECK FLANGE, SLIP-ON FLANGE, BLIND FLANGE, HIGH HUB BLIND FLANGE,
SOCKET WELD FLANGE. LAPJOINT FLANGE, THREADED FLANGE. RING TYPE JOINT FLANGE.
Pressure Class: 150, 300, 400, 600, 900, 1500, 2500
* ASME/ANSI B16.47(SERIES A & B): WELDING NECK FLANGE, BLIND FLANGE.
Pressure Class: 75, 150, 300, 400, 600, 900
* ASME/ANSI B16.36: (ORIFICE FLANGES) WELDING NECK FLANGE, SLIPON FLANGE, THREADED FLANGE.
Pressure Class: 300, 400, 600, 900, 1500, 2500
* ASTM/ANSI B16.48: ( Figure-8 blanks)
Pressure Class: 150, 300, 400, 600, 900, 1500, 2500
* MSS SP44: WELDING NECK FLANGE, BLIND FLANGE.
Pressure Class: 300, 400, 600, 900
* API 6A: WELDING NECK FLANGE, THREAD FLANGE, BLIND FLANGE.
Pressure: 2000Psi, 3000Psi, 5000Psi, 10000Psi, 15000Psi, 20000Psi, 25000Psi
