Basic Info.
Copper-Nickel Alloy Tube Sheet / Blind flange
1)ASTM B171 and other standards ,Forgings ,with Certificate of Europe PED 4.3 or 3.1 , 3.2 , 3.3
2)Material designation: BFe10-1-1 / C70600 / C7060X / CuNi10Fe1Mn / CuNi9010 / Cu90Ni10 and BFe30-1-1 / C71500 / CuNi30Mn1Fe / CuNi7030 / Cu70Ni30 or other alloy.
Material Brand of Copper-Nickel Alloy Tube Sheet / Blind flange:
| Grade | USA | U.K | Germany | Japan |
| China BG | ASTM | BS | DIN | JIS H |
| BFe10-1-1 | C70600 | CN102 | CuNi10Fe1Mn | C7060 |
| BFe30-1-1 | C71500 | CN107 | CuNi30Mn1Fe | C7150 |
Other materials: C46400 , C44300 , C36000 , CUAL10NI5FE4 , BS 1400 LGCS and other copper alloy metals.
3)Tubes temper: All tempers are available (Goods supply state: Annealed condition)
4)Dimensions: Outer diameter:Up to 2000mm Thickness: Up to 800mm or according to the buyers' requirements, and also length and tolerance subject to the buyer's decisions.
Copper-nickel UNS C70600 has a copper content of not less than 88.6%.
Tabulated below are the mechanical properties of UNS C70600 tubes as a function of heat treatment.
| Temper | Tensile Str. | Yield Str. | Elong. | Rockwell | |||
| B | C | F | 30T | ||||
| H55 | 414MPa (60ksi) | 393MPa (57ksi) | 10% | 72 | - | 100 | 70 |
| OS025 | 303MPa (44ksi) | 110MPa (16ksi) | 42% | 15 | - | 65 | 26 |
The chemical composition of UNS C70600 copper alloy is outlined in the following table.
| Elements | Content (%) |
| Nickel, Ni | 9.0-11.0 |
| Iron, Fe | 1.0-1.8 |
| Zinc, Zn | 1.0 |
| Manganese, Mn | 1.0 |
| Lead, Pb | 0.05 |
| Copper, Cu | Remainder |
Equivalent materials to UNS C70600 copper alloy are given in the table below.
| ASME SB111 | ASME SB171 | ASME SB359 | ASME SB466 | ASME SB467 |
| ASME SB395 | ASME SB543 | ASTM B111 | ASTM B151 | ASTM B122 |
| ASTM B171 | ASTM B359 | ASTM B395 | ASTM B432 | ASTM B466 |
| ASTM B469 | ASTM B543 | ASTM B608 | DIN 2.0872 | MIL C-15726 |
| MIL T-15005 | MIL T-16420 | MIL T-22214 | SAE J461 | SAE J463 |
